Hood Striker: Service and Repair

Hood Striker Pin

Removing






Perform the following:

- Open the hood - 1 -.

- Remove the bolts - 3 -.

- Remove the hood catch - 2 - from the hood - 1 -.

Installation






Perform the following:

Install the hood catch - 2 - in reverse order of removal.

Tightening specification - 3 -: 18 Nm

- Striker Pin, Adjusting, refer to => [ Hood Striker Pin ].
