Child Seat Tether Attachment: Service and Repair

Child Seat Anchor, Top Tether

Special tools, testers and auxiliary items required

• Trim removal wedge (3409)






Removing

- Lift out the outer trim panel - 1 - using the trim removal wedge (3409) - 2 -.











- Remove the screws - 4 - (4 Nm).

- Remove the bracket - 3 -.

- Remove the inner trim panel - 2 - from the backrest - 1 -.

Installation

- Install in reverse order of removal.
