Fender and Fender Bar Piece Noise Insulation

Fender and Fender Bar Piece Noise Insulation

• The illustration shows a left door hinge. The right door hinge is identical.

• There may be different noise insulation and foam pieces installed.






1 Noise insulation

• Inserted between the front fender and the upper A-pillar longitudinal member

• Not installed in all models

2 Front fender noise insulation

• Inserted between the front fender and the upper wheel housing longitudinal member

• Not installed in all models
