Steering Column Assembly Overview

Steering Column Assembly Overview

• Welding and straightening work on supporting or wheel carrying components of suspension is not permitted.

• Always replace self-locking nuts.

• Always replace corroded bolts/nuts.






1 Lateral Control Arm for Steering Column

• With mounting bracket.

2 Steering Column

• Removing and installing, refer to => [ Steering Column ] Steering Column.

3 Bolt

• 20 Nm

• Always replace if removed.

4 Brake Pedal Crash Brace

5 Clutch Pedal Crash Brace

6 Bolt

• 30 Nm

• Always replace if removed.
