Resetting With Scan Tool

Service interval display, reset

Service Reminder Indicator must be reset for:
Vehicle release inspection
Every service
(adapted)!

Connect diagnostic tester.
Switch ignition on.
Touch button/field on screen. GUIDED FUNCTIONS on screen.

If the displays indicated in the work procedure are not indicated on display: Refer to Operating instructions for Vehicle Diagnosis, Testing and Information System 5051 or Vehicle Diagnosis Service System VAS 5052

Press > button to confirm.

Select in succession:
Brand
Model
Model year
Engine Code
Confirm vehicle identification.

Select in succession:

"Instrument cluster" -arrow-.

This Image Is Used For Illustration Purposes Only.:

"Resetting Service Reminder Indicator (SRI)" .

Perform adaptation according to instructions of "GUIDED FUNCTIONS" .

End Adaptation

This Image Is Used For Illustration Purposes Only.:

Indicated on display:

Press the Go to button -arrow- on display.

This Image Is Used For Illustration Purposes Only.:

Indicated on display:

Press exit button -arrow- on display.
Press exit button in exit menu.
Turn off ignition and disconnect diagnostic connection.
Switch ignition on.
After switching on the ignition, service event is no longer indicated in the odometer display in the instrument panel insert.
