Large Roof Lid

Pillar and Side Trims, Convertible

Large Roof Lid

CAUTION!
• Prior to removal and installation of the large roof lid, remove the lid module from the side trim, refer to => [ Small Trim Lid Module Assembly Overview ] Pillar and Side Trims, Convertible Overview.

• There is a danger of damaging painted side trim parts!

Removal

- Remove the pressure rod. Refer to => [ Pressure Rod ]. Pressure Rod

- Fully loosen screws - 1 -.





- Fold the large roof lid away from the main frame of the lid module.

Installation

- To install, perform the steps used in removal in reverse order.
