Diagram 651/9 (Tracks 99-112)

IMPORTANT NOTE:
This manufacturer uses "Track" style wiring diagrams.
For information on how to use these diagrams effectively, please refer to Diagram Information and Instructions. Diagram Information and Instructions


Rear Lid Release Switch, Comfort System Central Control Module, Luggage Compartment Light





ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = lilac
ge = yellow
or = orange
rs = pink

E165 - Rear Lid Unlock Switch

F5 - Luggage Compartment Light Switch Central Locking System

J393 - Comfort System Central Control Module Central Locking System

T4k - 4-Pin Connector, in right luggage compartment

T5 - 5-Pin Connector, black, on C-pillar, left

T5g - 5-Pin Connector, black, on left rear lid, near lock cylinder

T23 - 23-Pin Connector, on J393

W3 - Luggage Compartment Light

(A40) - Plus Connection 1 (30) (in instrument panel wiring harness)

(A126) - Rear Lid Contact Switch Connection (in instrument panel wiring harness)

(B229) - High-Bus Connection (in interior wiring harness)

(B230) - Low-Bus Connection (in interior wiring harness)

1) - Through June 2007

2) - From July 2007

Previous Diagram 651/8 (Tracks 85-98)

Next Diagram 651/10 (Tracks 113-126)
