Fuses (SA) On Fuse Panel A, On Electronics Box High

Fuses in engine compartment

Fuses (SA) on fuse panel A, on electronics box High








Fuse Panel
Fuse Colors
200 A - purple
150 A - grey
125 A - pink
100 A - blue
80 A - white
70 A - brown
60 A - yellow
50 A - red
40 A - green
30 A - orange
