Diagram 630/3 (Tracks 15-28)

IMPORTANT NOTE:
This manufacturer uses "Track" style wiring diagrams.
For information on how to use these diagrams effectively, please refer to Diagram Information and Instructions. Diagram Information and Instructions


Ignition/Starter Switch, Clutch Pedal Starter Interlock Switch, Starter Lock/Clutch Pedal Switch Relay





ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = lilac
ge = yellow
or = orange
rs = pink

B - Starter

D - Ignition/Starter Switch

F194 - Clutch Pedal Starter Interlock Switch 2.5L BPS and BPR

J220 - Motronic Engine Control Module (ECM) Locations

J434 - Starter Lock/Clutch Pedal Switch Relay

S10 - Fuses (on fuse/relay panel)

T8 - 8-Pin Connector

T9i - 9-Pin Connector 1)

T10f - 10-Pin Connector 2)

T121 - 121-Pin Connector

(501) - Threaded Connection 2, terminal 30 (on relay panel)

(A2) - Plus Connection (15) (in instrument panel wiring harness)

(A32) - Plus Connection (30) (in instrument panel wiring harness)

(A52) - Plus Connection 2 (30) (in instrument panel wiring harness)

(D13) - Connection (50) (in right front wiring harness)

(D97) - Connection (50) (in right engine compartment wiring harness)

* - Only models with manual transmission

--- - Only models with engine code BPR

1) - Through June 2007

2) - From July 2007
