Transmission Position Relay: Locations

Fig. 8 Park/Neutral position (PNP) relay -J226-, 09A, 5 Spd. A/T





Location
The relay is located on the additional relay carrier under the instrument panel, left.
Relay is marked with number 175 (arrow).

Location of Transmission Control Module -J217-





The control module (arrow) is located in the plenum chamber center/right.
