Home >> Volkswagen >> 2005 >> Passat Wagon 4Motion (3B6) L4-1.8L Turbo (AWM) >> Repair and Diagnosis >> Transmission and Drivetrain >> Differential Assembly >> Application and ID >> 01V, 5 SPD. A/T (AWD) >> Code Letters, Assembly Allocation, Ratios

Code Letters, Assembly Allocation, Ratios



Code letters, assembly allocation, ratios, 01V, 5 SPD. A/T (AWD)
