Clutch Mechanism, Servicing (Master Cylinder Secured to Clutch Pedal By A Pin): Overview

Overview, 01A, 5 SPD. M/T (AWD)
^ Obtain radio code for radios with anti-theft coding before disconnecting battery.
^ Disconnect battery Ground (GND) strap with ignition switched off.
^ If battery is re-connected, note work after re-connecting battery.
^ Lubricate all bearing and contact surfaces with grease G 000 450 02.
^ Before working on foot pedal assembly, remove storage compartment on drivers side.





I. Pedal assembly, Left Hand Drive (LHD) vehicles, assembly overview.
II. Pedal assembly, Right Hand Drive (RHD) vehicles Final drive, Differential (rear) not included
III. Clutch hydraulic system, assembly overview.
