High-Mount Brake Light -M25- Wagon

High-mount Brake Light -M25- - Wagon From 10.00

Bulb holder, removing and installing

CAUTION:
- Switch off all electrical consumers.
- Switch off ignition and remove ignition key.







- Remove screws -arrowsA-, unclip trim -arrowsB- and remove.







- Depress locking clips -arrows- and remove bulb holder -1- from mounting -2-.

NOTE: The bulb holder base plate contains soldered-in light emitting diodes (LEDs) that are not replaceable. In the event of LED malfunction, replace complete bulb holder.
