01V, 5 SPD. A/T (FWD)



Fig. 16 Starting interlock relay -J207-, 01V, 5 SPD. A/T (FWD)





Location: Relay is located on relay plate behind dash panel, left.

Relay is marked with number "204" -arrow-.
