Introduction

Bulletin Number:
0100-02

Group:
01

Number:
00-02

Date:
Apr. 24, 2000

Subject:
Driver's Side Airbag, On Board Diagnostic (OBD)

Model(s):
All 2000-on

Service

Ref. 1 Of 2:

Additional diagnostic procedures and a new special service tool have been established to prevent unnecessary replacement of airbag components. In addition, certain airbag wiring harness terminals and connectors can now be repaired using VAS 1978 Wire Harness Repair kit. Follow all diagnostic procedures in this bulletin and Repair Manual before beginning repair.

CAUTION! ALWAYS review and follow all CAUTIONS and WARNINGS in the Repair Manual regarding airbags!
