Condenser HVAC: Service and Repair

Condenser, Removing and Installing







First do the following:
- Discharge refrigerant system
- Drain coolant
- Disconnect refrigerant pipes at condenser

CAUTION: Immediately plug open connections on A/C components to prevent dirt and moisture contamination.

- Bring front end assembly (lock carrier) into service position.

1. Radiator
- Always use new coolant after replacement
2. Condenser
3. Bolt
- 8 Nm (71 in lb)
4. Lock carrier
- Bring into service position
