Explanation of the PR Numbers 1BA, 1BC, 1BE, 1BB, 1BF and 1BP

Explanation of the PR numbers 1BA, 1 BE, 1 BB and 1 BP
Various suspensions are available as optional equipment. These are identified by the PR numbers.

The suspensions installed in a vehicle is documented on the vehicle data plate with the relevant PR number.





Example of a vehicle data sticker
In this example the vehicle is equipped with the standard suspension 1 BA -arrow-.

The vehicle data sticker is located in the spare wheel recess and in service booklet.


The following table explains the PR numbers. This is relevant for the vehicle alignment.

Standard suspension: 1BA/1BC
Sport suspension: 1BE
Heavy duty suspension: 1BB/1BP
Special suspension(1): 1BF
(1) for vehicles with constand load less than or equal to 100 kg.
