Troubleshooting With V.A.G 1551 or VAS 5051 on ABS Mark 60

Troubleshooting with V.A.G 1551 scan tool or tester VAS 5051 on ABS Mark 60 (flow chart)
- Connect V.A.G 1551 scan tool or tester VAS 5051 and check DTC memory 02 again.
- Erase DTC memory (05)
- Perform test drive at more than 20 km/h (13 mph) and allow the ABS regulate braking.
- Check DTC memory again after test drive. If "No DTC recognized" appears on display of V.A.G 1551 scan tool or tester VAS 5051 after repair DTCs and performing test drive, the On Board Diagnostic (OBD) is completed.
