Fire Extinguisher Bracket (Passengers Side) - Assembly Overview



Fire Extinguisher Bracket (Passengers Side) - Assembly Overview







1 - Passengers side seat
2 - Combination nut
3 - Sheet-metal screw
4 - Fire extinguisher
5 - Fire extinguisher bracket
6 - Bolt
- 2x
