New Beetle (1C1) L4-2.0L (AZG)
>>
Repair and Diagnosis
>>
A L L Diagnostic Trouble Codes ( DTC )
>>
Testing and Inspection
>>
Manufacturer Code Charts
>>
Engine Control System
>>
DTC 17574
DTC 17574
DTC P1166 - Part 1:
DTC P1166 - Part 2:
