Additional Bolts At Front Valance Spoiler, Installing

Additional Bolts At Front Valance Spoiler, Installing

CAUTION: When installing front valance spoiler, additional bolts must be installed on both sides.

Additional bolts (Rear view)
- Drill with 4 mm drill the front valance spoiler and wheel housing liner. Hole must be approx. 10 mm away from both outer edges, dimension - a - = 10 mm







1 - Front valance spoiler
2 - Bolts
- 2 Nm

3 - Additional bolts
- 2 Nm

4 - Front wheel housing liner
- Install speed nut on front valance spoiler and then bolt front wheel housing liner and front valance spoiler, item - 3 -.

Additional bolts (Front view)







1 - Front wheel housing liner
2 - Additional bolts
- 2 Nm

3 - Bolts
- 2 Nm

4 - Front valance spoiler
