Home >> Toyota >> 1994 >> Supra L6-183 2997cc 3.0L DOHC Turbo (2JZ-GTE) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Powertrain Management >> Computers and Control Systems >> Engine Control Module

Engine Control Module

Electronic Control Module (ECM) Circuit Schematic




Part 1





Part 2
