Corolla Sedan L4-1587cc 1.6L DOHC (4A-GE)
>>
Repair and Diagnosis
>>
Transmission and Drivetrain
>>
Differential Assembly
>>
Specifications
>>
D/F Torque Data
D/F Torque Data
Rear Differential (4WD), Carrier Torque:
