Steering Angle Sensor Communication

DTC C0071 STEERING ANGLE SENSOR COMMUNICATION
DTC DETECTING CONDITION:
Signal does not come from the steering angle sensor.

TROUBLE SYMPTOM: VDC does not operate.











WIRING DIAGRAM
