P0509

DTC P0509 - IDLE CONTROL SYSTEM CIRCUIT HIGH

DTC DETECTING CONDITION
Detected simultaneously at fault occurrence

TROUBLE SYMPTOM
- Erroneous idling
- Engine stalls.
- Engine breathing

CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode and Inspection Mode.
