With Subaru Select Monitor

CLEAR MEMORY MODE
1. On the <
> display screen, select {2. Each System Check} and press the <> key.
2. On the <> display screen, select {Brake System} and press the <> key.
3. Press the <> key after the engine type is displayed.
4. On the <> display screen, select {Clear Memory} and press the <> key.
5. When "Done" and "turn ignition switch OFF" are shown on the display screen, turn the Subaru Select Monitor and ignition switch to OFF.

NOTE: For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.





FUNCTION CHECK
