P0734

P0734 - GEAR 4 INCORRECT RATIO

DTC DETECTING CONDITION
- Two consecutive driving cycles with fault

TROUBLE SYMPTOM
- Shift point too high or too low; engine brake not effected in "3" range; excessive shift shock; excessive tight corner "braking"

CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode Ref. to OPERATION, Clear Memory Mode. and Inspection Mode Ref. to OPERATION, Inspection Mode.

Wiring Diagram:

WIRING DIAGRAM
