Seals and Gaskets: Service and Repair
A: REPLACEMENT1. Clean transmission exterior.
2. Drain ATF completely.
NOTE: Tighten ATF drain plug after draining ATF.
Tightening torque: 25 Nm (2.5 kgf-m, 18.1 ft. lbs.)
3. Remove the rear exhaust pipe and muffler.
4. Remove the heat shield cover.
5. Remove the propeller shaft.
6. Using ST, remove the oil seal.
ST 398527700 PULLER ASSY
7. Using ST, install the oil seal.
ST 498057300 INSTALLER
8. Install the propeller shaft.
9. Install the heat shield cover.
10. Install the rear exhaust pipe and muffler.
11. Pour ATF and check the ATF level.
