Automatic Transmission Dipstick - Dipstick Tube: Service and Repair

A: REMOVAL





1) Remove the oil charger pipe, and remove the O-ring from the flange face. Attach the O-ring to the pipe.

B: INSTALLATION





1) Install the oil charger pipe with O-ring.

CAUTION: Be careful not to damage the O-ring.

Tightening torque: 41 Nm (4.2 kgf-cm, 30.4 ft. lbs.)

C: INSPECTION
Make sure the oil charger pipe is not deformed or otherwise damaged.
