Radiator Main Fan System

INSPECTION

















TROUBLE SYMPTOM:
^ Radiator main fan does not rotate in low speed under the following conditions:
1. Coolant temperature 95°C (203°F) or more.
2. A/C switch set to OFF.
^ Radiator main fan does not rotate in middle speed under the following conditions:
1. Coolant temperature 95°C (203°F) or less.
2. A/C switch set to ON and A/C temperature at the lowest position.
^ Radiator main fan does not rotate in high speed under the following conditions:
1. Coolant temperature 95°C (203°F) or more.
2. A/C switch set to ON and A/C temperature at the lowest position.

NOTE: Inspection by your Subaru distributor is required, because probable cause is deterioration of multiple parts.
