P0506

DTC P0506 - IDLE CONTROL SYSTEM RPM LOWER THAN EXPECTED

DTC DETECTING CONDITION:
- Two consecutive driving cycles with fault

TROUBLE SYMPTOM:
- Engine is difficult to start.
- Engine does not start.
- Erroneous idling
- Engine stalls.

CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode and Inspection Mode .
