Mode F11, Line Pressure Duty
MODE F11 LINE PRESSURE DUTY (PLDTY)
Condition
- After sufficient warm-up.
- Ignition "ON" (Engine "OFF").
- "N" range.
Specified Data
- Throttle fully closed: 100%.
- Throttle fully open :15%.
Condition
- After sufficient warm-up.
- Ignition "ON" (Engine "OFF").
- "N" range.
Specified Data
- Throttle fully closed: 100%.
- Throttle fully open :15%.
