AR77.30-P-1112MCU Remove/Install Guide Tube For Drive Cable

AR77.30-P-1112MCU Remove/Install Guide Tube For Drive Cable


Shown on left side of vehicle







1 Guide tube
2 Rear soft top
3 Screw
4 Roof cassette seal
5 Screw
6 Screw







1 Guide tube
8 Cable tie
9 Roof cassette
10 Screw
11 Screw
