Installation

PARKING BRAKE: PARKING BRAKE SWITCH: INSTALLATION

1. INSTALL PARKING BRAKE SWITCH ASSEMBLY

(a) Install the parking brake switch with the screw.





Torque : 0.9 Nm (9 kgf-cm, 8 in-lbf)

(b) Connect the parking brake switch connector.

2. INSTALL REAR CONSOLE BOX SUB-ASSEMBLY Installation

3. INSTALL CONSOLE BOX CARPET Installation

4. INSTALL REAR CONSOLE BOX COVER Installation

5. INSTALL UPPER CONSOLE PANEL Installation

6. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) Installation
