Home >> Scion >> 2010 >> xD L4-1.8L (2ZR-FE) >> Repair and Diagnosis >> Specifications >> Mechanical Specifications >> Axle Shaft Assembly >> Drive Shaft >> Torque Specifications

Torque Specifications





SERVICE SPECIFICATIONS: DRIVE SHAFT: TORQUE SPECIFICATIONS

FRONT DRIVE SHAFT ASSEMBLY:
