Installation








MIRROR: INNER REAR VIEW MIRROR: INSTALLATION

INSTALLATION





1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY
(a) Install the inner rear view mirror as shown in the illustration.
(b) Install the cover.
