Removal

LIGHTING: SIDE TURN SIGNAL LIGHT ASSEMBLY: REMOVAL

REMOVAL
HINT:
- Use the same procedures for the RH side and LH side.
- The procedures listed below are for the LH side.

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

2. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY LH Removal

3. REMOVE SIDE TURN SIGNAL LIGHT LENS LH





(a) Detach the 4 claws and remove the cover.






(b) Remove the 2 screws.
(c) Disconnect the connector and remove the side turn signal light lens LH.
