Instrument Panel Retainer Replacement - Left Side

Instrument Panel Retainer Replacement - Left Side

Removal Procedure

1. Remove the front floor console. Refer to Front Floor Console Replacement (Service and Repair) .




2. Remove the instrument panel (I/P) retainer - left side.

* Remove the 2 bolts (arrows).
* Remove the I/P retainer (1).




Installation Procedure


Notice: Refer to Fastener Notice (Fastener Notice) .

1. Install the I/P retainer, left side.

Tighten the 4 bolts to 13 N.m (113 lb in).

2. Install the front floor console. Refer to Front Floor Console Replacement (Service and Repair) .
