Digital Radio Receiver Replacement

Digital Radio Receiver Replacement

Removal Procedure

Caution: Refer to Battery Disconnect Caution (Battery Disconnect Caution) .
1. Disconnect the battery.




2. Remove the instrument panel (I/P) compartment.

* Open the I/P compartment door.
* Remove the 4 bolts (1).
* Disconnect the wiring harness plug.
* Remove the I/P compartment.





3. Remove the digital radio receiver.

* Disconnect the 2 wiring harness plugs (1).
* Release the 2 retaining lugs (2).
* Remove the digital radio receiver to the vehicle center.





4. Remove the digital radio receiver bracket.
Disconnect the bracket from the crossmember (1) and remove.



Installation Procedure

1. Install the digital radio receiver bracket.
Install the bracket into the crossmember.
2. Install the digital radio receiver.

* Install the receiver into the bracket.
* Connect the 2 wiring harness plugs.

3. Install the I/P compartment.
Connect the wiring harness plug.

Notice: Refer to Fastener Notice (Fastener Notice) .

4. Fasten the I/P compartment.

Tighten the 4 screws to 4 N.m (35 lb in).

5. Connect the battery.
6. For reprogramming procedures, refer to Control Module References (Programming and Relearning) .
