C0267
DTC C0267
Circuit Description
The body control module (BCM) monitors the brake fluid level in the master cylinder reservoir via the brake fluid level switch.
DTC Descriptor
This diagnostic procedure supports the following DTC:
DTC C0267 Low Brake Fluid Indicated
DTC C0129 Low Brake Fluid Circuit High
Conditions for Running the DTC
The ignition switch is in the ON position for 60 seconds or more.
Conditions for Setting the DTC
* The BCM detects a low brake fluid level condition for more then 60 seconds.
* The BCM detects a short to voltage in the brake fluid level signal circuit.
* The BCM detects an open in the brake fluid level signal circuit.
Action Taken When the DTC Sets
The red brake warning indicator turns ON.
Conditions for Clearing the DTC
The conditions for setting the DTC are no longer present and you use the scan tool Clear DTCs function.
Diagnostic Aids
A lower than normal brake fluid level in the master cylinder may cause the brake fluid level switch to close when the vehicle makes sharp turns or sudden stops. Low brake fluid level may be caused by a brake fluid leak or worn disc brake pads.
Thoroughly inspect connections or circuitry that may cause an intermittent malfunction.
