Rear Coil Spring Insulators Replacement

Coil Spring Insulators Replacement

Removal Procedure





1. Raise and support the vehicle. Refer to Vehicle Lifting.
2. Remove the rear spring.
3. Remove the coil spring insulator from the rear axle assembly.

Installation Procedure





1. Install the coil spring insulator to the rear axle assembly.
2. Install the rear spring, taking care to properly seat the spring to the insulator.
