Saturn
>>
2005
>>
ION L4-2.0L SC VIN P
>>
Repair and Diagnosis
>>
Engine, Cooling and Exhaust
>>
Exhaust System
>>
Exhaust Manifold
>>
Specifications
Exhaust Manifold: Specifications
NEW
Exhaust Manifold
to Cylinder Head Nuts
14 Nm (124 inch lbs.)
Exhaust Manifold
Nuts (2.0L LSJ)
NEW
Exhaust Manifold
to Cylinder Head Nuts
13 Nm (115 inch lbs.)
Exhaust Manifold
Nuts (2.2L L61)
