4. Water Crossover Removal

Water Crossover Removal





1. Remove the coolant intake hose.
2. Remove the heater hose.
3. Remove the coolant bridge bolts.
4. Remove the coolant bridge upper seals.
5. Remove the coolant bridge.
6. Remove the coolant bridge lower seals.
