C0550

DTC C0550





Circuit Description
The EBCM performs several self-tests for internal problems which may affect proper operation.

Conditions for Running the DTC
The ignition is ON.

Conditions for Setting the DTC
The EBCM detects an internal malfunction.

Action Taken When the DTC Sets
^ The EBCM disables the ABS/DRP/TCS.
^ The ABS indicator turns ON.
^ The traction off indicator turns on.

Conditions for Clearing the DTC
Certain conditions that may cause this DTC to set cannot be cleared. Other conditions that may cause this DTC to set may be cleared, at least temporarily, by using the scan tool Clear DTCs function.

Diagnostic Aids
Replace the EBCM if this DTC continues to set intermittently.
