General Information

AM/FM Stereo With Cassette And 6 Disc In-Disc CD Changer/Player Part 1:

AM/FM Stereo With Cassette And 6 Disc In-Disc CD Changer/Player Part 2:

FEATURES AND BENEFITS
^ 6 AM /12 FM Radio Station Presets: Programmable by following two steps:
1. Tune to desired station
2. Press and hold the desired preset button for approximately one second (until an audio confirmation beep is heard).
^ A. SET (Automatic Station Set): Automatically programs the preset buttons to the strongest local radio stations. The originally programmed presets are retained.
^ Electronic Tuning: Automatically locks in station signals for best possible reception.
^ Seek Tuning: Provides up and down seek capability for radio band to search for the next receivable station.
^ Scan Tuning: Samples station selections for five seconds and then automatically moves to next station.
^ Automatic Loudness Compensation: Full depth of sound can be heard at low volume levels.
^ Auto Tone Control (ATC):

Allows the sound to be tailored to meet individual preferences. Seven different selectable preset tones are available along with the CSIM (custom) tone. The CSTM tone is set by pressing and rotating the BASS/TREB/FADE/BAL knob.

The setting can be permanently or temporarily displayed by pressing and holding the BASS/TREB/FADE/BAL knob until an audible tone is heard.

^ Rotary Bass, Treble, fade, and Balance Control Knob: The BASS/TREB/FADE/BAL knob allows the bass, treble, fade, and balance. Push the knob until the desired mode is displayed. then rotate knob to adjust.
^ The Time of Day (Clock) will be displayed when:
1. The ignition is turned OUT and the radio power is either On or Off.
2. The ignition is turned On and the radio power is Off.
3. The ignition is turned on, the radio is On, and the tune, seek, scan, or preset function has not been activated for ten seconds.
^ Setting the Time of Day (Clock):
1. Push and hold the RCL (Recall) button.
2. While holding the RCL button, push the left side of the auto tone button until the correct hour appears.
3. While holding the RCL button, push the right side of the auto tone button until the correct minutes appears.
4. Release the RCL button when complete.
^ Dimming:

All radios feature continuously dimmable back lighting for the graphics on the push buttons and trim plate. The LCD display is back lit in ignition On or (Accy) accessory positions.

^ Theft Deterrent Feature: Refer to "Theft Deterrent Feature".
^ On-Board Diagnostics: On-board diagnostics (OBD) are available to check:
^ If any diagnostic trouble codes (DTCs) have been set.
^ If speakers are functioning correctly at two different tones.
^ If all segments on the LCD light up. If all buttons are working. Equalization mode setting
^ Signal strength read by the radio.
