P1868

Schematic:

The TCM contains a program to keep track of transaxle fluid life remaining. The program uses run time and transaxle fluid temperature to determine fluid life remaining. When fluid life remaining is less than 5%, DTC P1868 sets. P1868 is a type C DTC.

DTC PARAMETERS
DTC P1868 Will set if TCM detects the fluid lift counter is less than 5% remaining.

DIAGNOSTIC AIDS
- Perform a fluid and filter change.
- Clear code and reset oil life remaining to 100%.
