AM/FM Stereo Cassette Radio

Product Overview: AM/FM Stereo Cassette Radio:




FEATURES AND BENEFITS
^ Auto Reverse Cassette:
Plays both sides of a tape with no need to eject.
^ Soft Touch Cassette Controls:
Controls cassette functions: Reverse (REV), Program (PRG), and Forward (FWD).
^ Dolby(R) B Noise Reduction (Switchable):
Reduces hiss on Dolby(R) encoded tapes.
^ Automatic Metal Tape Equalization:
Allows better sound quality when using metal tapes. "MTL" will appear on the display when a metal tape is playing.
^ Fast Forward/Reverse Functions:
Rewinds or forwards the tape to the desired location. The arrows on the display show which side of the tape is playing. The up arrow refers to the top side of the tape. The down arrow refers to the bottom side of the tape.
^ Power Loading/Unloading:
Cassette is loaded with power assist.
^ Power Off Tape Protection:
Prevents tape damage if the ignition is turned off while tape is in play mode.
^ Tape Clean Indicator:
Reminds the user to clean the cassette head after 30 hours of use.
Note: Also includes all features and benefits listed for the AM/FM Stereo Radio.
