Throttle Body Assembly Installation

Throttle Body Assembly Installation (LAU or LBW)

1. Install the NEW throttle body gasket (3).





2. Install the throttle body (2).
3. Refer to Fastener Caution.

Install the throttle unit's 4 pipe bolts (1) and tighten to 10 Nm (89 lb in).
