Rear Washer Not Working







Fault symptom
No washing of rear window

Conditions
Turn Ignition On
Rear window washer activated

Checking the wiring harness
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
