Crimp J99, Main Wiring Harness

Crimp J99, Main Wiring Harness:

List Of Components:

Location:

4D: Approx. 225 mm from branching of left seat towards branching of seat-belt tensioner, left B pillar

5D: Approx. 170 mm from branching of left seat towards grounding point G33P/S

CV: Approx. 470 mm from branching point grounding point G33P/S towards the LH rear door

Crimp connection J348, main wiring harness

Crimp J380, main wiring harness CV
